| NON-ASBESTOS JOINT SHEET |
| HENGSENG NO.:HLS200 SERIES |
 HLS200 |
 |
| This products
is made from "Kevlar" Aramid fiber,Vegetable fiber,Mineral
fiber,compressed and calendered under high t emperature and
pressure into a sheet form.It eliminates asbestos-rubber sheet
essentially and thoroughly. |
|
| Main Properties |
| Length(mm)
|
Width |
Thickness |
Density(g/cm3) |
| 1000 4000 2000 |
<1500 |
0.5,1.0,1.5,2.0,3.0,4.0,5.0 |
1.8-2.0 |
|
|
| Main Properties |
| Colour |
ºÚ
black |
ºì
red |
ÂÌ°×
green-white |
| Style |
210 |
220 |
230 |
| Temperature°C |
400 |
300 |
300 |
| Pressure(Mpa) |
10 |
7 |
7 |
| Compressibility(%)ASTM F36 |
7-17 |
7-17 |
7-17 |
| Recovery(%)ASTM F36 |
>45 |
>45 |
>45 |
| Horizontal Tensile Strrength(N/mm2)ASTM
F52 |
10 |
12 |
15 |
Oil Resistance
ASTM NO.3 Oil-5h 150C
Thickness Increase(%)
Weight Increase(%)
Variation of Tensile Strength(N/mm2)ASTM
F152 |
0-5 |
0-5 |
0-5 |
| <=10 |
<=10 |
<=10 |
| -30 |
-30 |
-30 |
| Leakage rate(ml/min)DIN 3535/4 |
0.5 |
0.5 |
0.5 |
lgnition loss(%) JB/T 6628
(Under300°C Temp igniting for 3 hours) |
<=8 |
<=8 |
<=8 |
| Stress Relaxation (N/mm2)DIN 52913 |
<=25 |
<=25 |
<=25 |
|
|
| Above Products Can be reinforced with tin
steel wire mesh,copper wire mesh,and AISI304wire mesh,etc. |
| |
|
|
| |
|
